Technical parameters |
|---|
| Length of the working table |
599.4 mm |
| Width of the working table |
378.5 mm |
| Maximum table load (evenly distributed) |
249.5 kg |
| Power of the spindle drive |
4.1 kW |
| Number of tools in the magazine |
20 pcs |
| Minimum rotary speed of the vertical spindle |
30 1/min |
| Maximum rotary speed of the vertical spindle |
6000 1/min |
| Minimum distance of the spindle from the table |
149.9 mm |
| Maximum distance of the spindle from the table |
619.8 mm |
| Travel length X-axis (mechanical feed) |
599.9 mm |
| Travel length Y-axis (mechanical feed) |
410 mm |
| Travel length Z-axis (mechanical feed) |
469.9 mm |
| Maximum feed rate in X-axis |
249.8 mm/s |
| Maximum feed rate in Y-axis |
249.8 mm/s |
| Maximum feed rate in Z-axis |
199.8 mm/s |
| Machine height |
2705.1 mm |
| Machine length |
3683 mm |
| Machine width |
2819.4 mm |
| Machine weight |
4.5 t |
